Shimano CUES CS-LG400-10 11-48T Cassette

A silver 11-48T 10-speed LINKGLIDE cassette that takes an 11-speed chain. This CS-LG400-10 ratio is 11-13-15-17-20-23-28-34-41-48T, with 10 steel sprockets, on an HG spline M freehub. Shimano lists the chain as LINKGLIDE or HG 11-speed, not a traditional 10-speed chain.

At a glance

• Category: 10-speed cassette
• Brand: Shimano (Japan), LINKGLIDE
• Model: CS-LG400-10, silver 11-48T only on this page
• Ratio: 11-13-15-17-20-23-28-34-41-48T
• Chain: LINKGLIDE or HG 11-speed
• Freehub: HG spline M (listed for 10/9/8-speed, MTB 11-speed, and 7-speed CS-HG400/HG210). Microspline, road 12-speed and road 12/11-speed HG spline L are not marked
• Sprockets: 10 steel, plated; steel plated lockring
• Shimano’s claim: up to three times the durability of HYPERGLIDE in high chain-tension conditions, with smooth shifting in both directions
• Pairs with: RD-U6000-GS, whose 10-speed maximum low sprocket is 48T

10-speed cassette, 11-speed chain

This is the easy mistake. The cassette is 10-speed, and the official chain row says LINKGLIDE or HG 11-speed. A leftover 10-speed HG chain is not the chain Shimano lists. Check the speed marking on the chain before ordering.

Shimano describes LINKGLIDE as a durable drivetrain for multi-purpose bikes and high-torque e-bikes. “Up to three times the durability of HYPERGLIDE” is Shimano’s statement for high chain tension, not a Jollymap test.

Who it suits

• A 1x10 LINKGLIDE bike that needs an 11-48T range for hills, cargo or an e-bike
• An HG spline M freehub, not Microspline and not a narrow road 11-speed freehub
• A rear derailleur that can take a 48T low sprocket. The match in this batch is RD-U6000-GS

Shimano also lists 11-39T and 11-43T. Those ratios are not this page, and this page is the silver finish only. If the freehub is uncertain, contact us rather than assuming every “10-speed” hub will take it.

Ratio and the matching derailleur

Source: Shimano productinfo. 48−11 = 37T is arithmetic from the official tooth counts, set against the derailleur’s 39T capacity.

A CUES hydraulic build uses the ST-U6030 / BR-U6030 rear set. The cable lever ST-U3030-10R is NEW SUPER SLR and belongs on a cable brake, not on the hydraulic caliper.

Contact us before ordering

Contact us with a close photo of the freehub body and the model of the rear derailleur.

Specifications

Brand	Shimano
Model	CS-LG400-10
Type	LINKGLIDE
Rear speeds	10
This ratio	11-13-15-17-20-23-28-34-41-48T
Other official ratios	11-39T, 11-43T (not this page)
Chain	LINKGLIDE, HG 11-speed
Freehub	HG spline M
Sprockets	10 steel, plated
Lockring	Steel, plated
Finish	Silver on this page. Shimano calls the look a premium metallic design
Official weight	Not published

Source: Shimano productinfo CS-LG400-10 and bike.shimano.com.

In the box

This page is the silver 11-48T cassette, including the steel lockring listed in the specification. Chain, derailleur and shifter are separate.

FAQ

Does this 10-speed cassette use a 10-speed chain?

No. The official chain is LINKGLIDE or HG 11-speed.

Will it fit a road 11-speed freehub?

Shimano does not mark it. The marked body is HG spline M. Road 12/11-speed HG spline L and Microspline are unmarked. Send a photo of the freehub if you are unsure.

Can it run with a derailleur limited to 11-36T or 11-42T?

This cassette’s low sprocket is 48T. RD-U6000-GS lists a minimum low sprocket of 48T, so that derailleur matches. A derailleur whose maximum low sprocket is under 48T should not be assumed to fit.

Are 11-39T and 11-43T on this page?

No. Shimano lists three ratios. This page is silver 11-48T only.

Specifications and components follow the manufacturer's latest release and may change without notice. If in doubt, please contact us to confirm before ordering.

Last updated: October 2026
